Spex Adjustable Lateral
Head Support

A superior adjustable lateral head control system with individualised ‘tuning’.

The Adjustable Lateral Head Support offers flexibility to adjust external lateral supports, enabling these to be placed in the optimal position for users with impaired control and tone.

An upgrade to swing-away laterals is available to enable easier transfers if necessary.

For even more support, you can install our Spex thoracic lateral pads onto the head pad to create an enhanced level of support required (Tip: the Spex curved pads work really well).

Spex Head Support pads are constructed from an internal aluminium shell covered by an injection moulded polyurethane foam to ensure smooth and comfortable support surface. The family of head support shapes have been geometrically and biomechanically designed to give greater support and stability for head positioning for wheelchair users. Along with the versatile Spex Stylo hardware, it’s possible to accommodate an extensive range of head positioning requirements.

Available in two sizes Adjustable Lateral 150 and 250.

Spex Adjustable Lateral Head Support

The following weights do not include the Ball Mount or Stylo Mechanisms.

Style Total Weight
Adjustable Lateral 150 955g
Adjustable Lateral 250 1,160g
Style Adjustable Lateral 150 Adjustable Lateral 250
Code 1275-0061-000 1275-0062-000
Width (A) 175mm 220mm
Depth (B) 220mm 220mm
Height (C) 145mm 145mm
Bottom Thickness (D) 45mm 45mm
Top Thickness (E) 25mm 25mm
Edge Thickness (F) 55mm 55mm
Lateral Wing Thickness (G) 40mm 40mm
Lateral Wing Length (H) 155mm 155mm
