Spex Classic
Back Support

Spex cube contouring system allows on-the-spot customisations for torso comfort and asymmetry needs

Easily solve upper torso needs for most wheelchair users with the Spex exceptional upholstery section. Incorporates Spex contouring cube system to allow on-the-spot customisations for torso comfort and asymmetry needs.

Rectangle shape style fits between the wheelchair canes, while T shape sits in front of the wheelchair canes. The Surface style also sits in front of the canes and gives greater support in the shoulder and pelvic areas.

  • Effortless customisations
  • On-the-spot adaptions for changing postural needs
  • Instant results
  • Cubes can be removed and added at any time
  • Contouring doesn’t move or slip out of adjustment
  • Additional contouring support wedges can be used to further enhance the degree of contouring.
Description
Clinical
Functional

Designed for the individual who:

  • Requires a comfortable back support to reduce torso pain
  • Requires spinal alignment and support
  • Has skin breakdown/pressure care needs
  • Has bony or protruding skeletal prominences
  • Have changing postural needs
  • Pertains a maladaptive or asymmetric posture



For Mild Bony Prominences For Immersion For Asymmetry
Without even adjusting the cube system, the Spex back support has slight contouring and integrates a comfortable pressure reducing foam surface layer to absorb mild bony prominences and asymmetries for uniform torso contact. For individuals that require immersion into the back support, simply adjust the cube contouring cell system to configure for a perfect fit and shape for the user’s back. For asymmetrical or maladaptive postures, the contour can be arranged to provide the matching shape required to support the user’s torso profile.



  • Comfortable pressure reducing foam surface layer to absorb bony prominences.
  • Cube contouring cell system provides configurations for a perfect fit and shape for the client.
  • Customisation to contouring are performed on-the-spot.
  • Created as the solution-solver for asymmetrical back postures.
  • Modular componentry means you can ‘mix and match’ with different lateral pad options and positioning supports.
  • Offers exceptional back/shoulder contact.
  • Sustainable choice for issuing to other users
  • Dual-layer cover reduces shear forces, and breathable air-mesh on back support sides counters moisture and temperature
Videos &
Downloads
How to use the Contouring Chart
Comparison: Spex Classic and SuperShape Back Supports
Specifications
Weight Capacity
Size Options
Product Codes
Back Support Size 10″-15″ (25.4-38 cm) 16″-20″ (41-51 cm) 21″+ (53 cm+)
Maximum Occupant Weight 200 lb (90 kg) 300 lb (136 kg) Must use Heavy-Duty brackets
400 lb (180 kg)
Maximum Occupant Weight with Heavy-Duty brackets 300 lb (136 kg) 400 lb (180 kg)



Thickness of the back support is 7cm. The Spex Classic Back Support is designed to be contoured and this measurement only reflects the thickness without any of this contouring. Therefore the back support thickness will likely be less than 7cm in some sections and more in others.

Spex Classic Back Support fits between wheelchair canes.

Width Height Rectangle Shape Code
10″ 12″ 1255-1012-0SS
14″ 1255-1014-0SS
16″ 1255-1016-0SS
11″ 12″ 1255-1112-0SS
14″ 1255-1114-0SS
16″ 1255-1116-0SS
12″ 14″ 1255-1214-0SS
16″ 1255-1216-0SS
18″ 1255-1218-0SS
13″ 14″ 1255-1314-0SS
16″ 1255-1316-0SS
18″ 1255-1318-0SS
14″ 16″ 1255-1416-0SS
18″ 1255-1418-0SS
20″ 1255-1420-0SS
15″ 16″ 1255-1516-0SS
18″ 1255-1518-0SS
20″ 1255-1520-0SS
16″ 16″ 1255-1616-0SS
18″ 1255-1618-0SS
20″ 1255-1620-0SS
23″ 1255-1623-0SS
17″ 18″ 1255-1718-0SS
20″ 1255-1720-0SS
23″ 1255-1723-0SS
18″ 18″ 1255-1818-0SS
20″ 1255-1820-0SS
23″ 1255-1823-0SS
19″ 18″ 1255-1918-0SS
20″ 1255-1920-0SS
23″ 1255-1923-0SS
20″ 18″ 1255-2018-0SS
20″ 1255-2020-0SS
23″ 1255-2023-0SS
